Chauvet Professional Maverick Force 1 Spot 470W LED Moving Head Light Fixture with Gobos

470W LED Moving-head Spotlight Fixture with 5-facet Prism, CMY + CTO Color Mixing, Color Wheel, Zoom Optics, 2 Gobo Wheels, and Animation Wheel

Maverick Force 1 Spot is a lightweight moving head with a big presence. The tour-ready unit features an output of 20,000 lumens and an artillery of speedy effects in a deceptively compact frame, just under 50lbs. Maverick Force 1 Spot features CMY + CTO color-mixing, a color wheel with a CTB and CRI option, and an extensive zoom range of 7 to over 50 degrees that maintains a flat field of focus even when fully wide. Motorized iris, focus, zoom, and frost capabilities, alongside a 5-facet rotating prism give an abundance of tools for beam shaping as well. Custom glass gobos created in collaboration with leading designers, and a continuous animation wheel can all be stacked on top of each other. Control as you see fit with DMX, sACN, Art-Net or W-DMX.

AT A GLANCE

• Fully featured, compact and lightweight 470 W LED yoke spot fixture including CMY + CTO color mixing, a color wheel, zoom optics, and two gobo wheels, one rotating, and one static, and an animation wheel

• 16-bit dimming of master dimmer for smooth control of fades

• Variable CMY + CTO color mixing system to create a wide pallet of colors

• CRI and CTB filters on color wheel for added flexibility

• DMX, WDMX, sACN, and Art-Net for full flexibility of control options

• RDM enabled for remote addressing and trouble shooting

• 6.3° to 54.4° zoom range for variable beam sizes

• Iris, 5-facet prism, and frost for beam control

• True 1 compatible power input

• Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup

• USB slot for software uploads

• Battery backup display with auto-rotate depending on fixture orientation


SPECIFICATIONS

• Optical

• Light Source: 1 LED (CW) 470 W, (4 A), 7500K, 50,000 hours life expectancy

• Color Temperature (at full): 7099 K

• CRI: 68.8

• CRI with CRI Filter: 89.4

• Front Lens Dia: 127 mm

• Beam Angle: 6.3° to 45.7°

• Field Angle: 7.3° to 53°

• Cutoff Angle: 7.6° to 54.4°

• Zoom Range: 6.3° to 54.4°

• Lumens - Source: 35,000

• Lumens - Output: 21,172

• Illuminance (6.3°): 43,485 lux @ 5 m

• Illuminance (54.4°): 1,793 lux @ 5 m

• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

• Dynamic Effects

• Pan and Tilt: 540°/270°

• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt

• Colors: 7 (including CRI and CTB filters) + white, split colors, continuous scroll at variable speeds

• Colors: CMY+ CTO flags

• Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds

• Gobos (2): 9 + open (9 glass), static, continuous scroll at variable speeds

• Gobo Size (1): Gobo Wheel 1 (rotating): 25.5 mm (outside), 20 mm (image), 1.1 mm (max. thickness)

• Animation wheel: static, motorized, continuous scroll at variable speeds

• Dimmer: Electronic

• Shutter/Strobe: Electronic

• Zoom: Motorized

• Focus: Motorized

• Frost: Motorized

• Iris: Motorized

• Prism: 5 Facets, motorized, rotating

• Strobe Rate: 0 to 20 Hz

• Move-in-Black: Yes

• Dim Curves: 4

• Construction / Physical

• Dimensions: 15.5 x 9.8 x 25.0 in (394 x 250 x 636 mm)

• Weight: 48 lb (21.8 kg)

• Exterior Color: Black

• Housing Material: High-impact flame-retardant polymer

• Connections

• Power Connection: Edison plug to Seetronic Powerkon IP65

• Power Input: Seetronic Powerkon IP65

• Data Connectors: 3- and 5-pin XLR, Amphenol XLR Net RJ45 Connectors in/out

• Cable Length (power): 5 ft (1.5 m)

• Control

• Control Protocol: Art-Net, sACN, DMX, W-DMX

• DMX Channels: 25 or 32

• Art-Net Channels: 25 or 32

• Modes/Personalities: 2 personalities (25, 32)

• Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

• Power and Current: 670 W, 6.70 A @ 100 V, 60 Hz

• Power and Current: 660 W, 5.45 A @ 120 V, 60 Hz

• Power and Current: 637 W, 3.10 A @ 208 V, 60 Hz

• Power and Current: 632 W, 2.79 A @ 230 V, 50 Hz

• Power and Current: 630 W, 2.70 A @ 240 V, 50 Hz

• Power and Current (resting): 80 W, 0.801 A @ 100 V, 60 Hz

• Power and Current (resting): 80 W, 0.665 A @ 120 V, 60 Hz

• Power and Current (resting): 84 W, 0.397 A @ 208 V, 60 Hz

• Power and Current (resting): 84 W, 0.356 A @ 230 V, 50 Hz

• Power and Current (resting): 89 W, 0.361 A @ 240 V, 50 Hz

• Power Linking 12 A: 0@100 V, 2@120 V, 3@208 V, 4@230 V, 4@240 V

• Certifications / Qualifications

• CE, MET, FCC

• IP Rating: IP20, dry location

• Noise Level (ambient): 37 dB level @ 1 m

• Noise Level (Static - Full): 47.3 dB level @ 1 m

• Noise Level (Static - Eco): 40.7 dB level @ 1 m

• Noise Level (Static - Auto): 40.9 dB level @ 1 m

• Noise Level (Max): 49.5 dB level @ 1 m

• Temperature (startup): -4 °F to 113 °F (-20 °C to 45 °C)

• Temperature (operating): -22 °F to 113 °F (-30 °C to 45 °C)

• What's Included

• Maverick Force 1 Spot

• Seetronic Powerkon IP65 power cord

• 2 Omega brackets with mounting hardware

• Quick Reference Guide

• Optional Accessories

• Professional Clamps: CTC-50HC, CTC-50HCN

• Safety Cable: SC-07

• DMX cables

• Ethercon Extension cables

• IP Rated Seetronic Powerkon Extensions

• Flight Case

• UPLOAD_08 software uploader
