Neutrik NP3TT-P-AU-R 4.4mm (0.173") TT Bantam Plug (Red/Gold)

Red/Gold Neutrik NP3TT-P-AU-R 4.4 mm TT Bantam cable plug

This Red/Gold Neutrik NP3TT-P-AU-R is a male 4.4 mm (0.173-inch) TT Bantam cable-end plug with a Red plastic housing and gold-plated contacts. It is intended for compatible TT patch panels and accepts 4.0–4.8 mm outside-diameter cable. This listing is for one connector, not a finished patch cable or a box of 100.

Choose your housing color

This is the Red/Gold version. For the Black housing with gold-plated contacts, see the Neutrik NP3TT-P-AU-B Black/Gold.

Check the patch-panel format and cable fit

Confirm that your patch panel uses 4.4 mm TT Bantam connections; this is not a 1/4-inch or 3.5 mm plug. Match tip, ring, and sleeve wiring to your patch system's requirements. Check both the 4.0–4.8 mm cable-jacket fit and the listed wire size of 0.25 mm² / 24 AWG.

Solder and crimp assembly required

The tip and ring connections are soldered. The sleeve/shield connection uses a hex crimp that also provides cable retention. The listed shield-crimp size is 5.41 mm hex, according to IEC 60803, die designation D. The existing assembly information specifies a standard RG58 crimp tool; verify the actual die size and follow Neutrik's preparation instructions rather than choosing a tool by name alone.

Prepare the shield and conductors as instructed, make the solder and crimp connections, then check continuity, tip/ring/sleeve routing, shorts, and cable retention before use. This is not a solderless connector or an all-solder termination.

Features

• Male 4.4 mm TT Bantam plug for compatible pro-audio patch panels.
• Red plastic housing and gold-plated contacts.
• Solder termination for tip and ring.
• Hex-crimp shield termination and cable retention.
• Colored sleeves available separately for coding and marking.
• Listed lifetime of more than 1,000 mating cycles.

Electrical specifications

• Model: NP3TT-P-AU-R
• Contact resistance: Depends on mating connector
• Dielectric strength: 1 kV DC
• Initial insulation resistance: >2 GΩ
• Rated current per contact: Depends on mating connector
• Rated voltage: <50 V

Mechanical and material specifications

• Plug format: 4.4 mm, 0.173-inch TT Bantam
• Gender: Male
• Cable outside diameter: 4.0–4.8 mm
• Listed wire size: 0.25 mm² / 24 AWG
• Shield crimp: 5.41 mm hex, IEC 60803, die designation D
• Termination: Tip/ring solder; sleeve/shield hex crimp
• Lifetime: More than 1,000 mating cycles
• Bushing: Polyacetal, POM, and polyurethane
• Contact plating: 0.2 µm gold, TRIBOR
• Tip contact: Bronze, CuSn6
• Insert: Polyamide, PA 6.6, 30% glass reinforced
• Shell: Brass, CuZn39Pb3
• Housing: Red polyamide, 30% glass reinforced

Environmental specifications

• Standard compliance: MIL-P-642/13
• Solderability: Complies with IEC 68-2-20
• Temperature range: −20°C to +65°C
