Key Features
- Supports 4k and 3D Video
- Ultra-Flexible Cable
- Low-Profile Connector
- Fully Shielded
Description
Connect a multimedia device to a display and support the latest HDMI features including Ultra HD
The Ultra Flexible High Speed HDMI Cable with Low Profile Connectors is perfect for home theater or desktop audio video applications requiring high speed HDMI features and video resolutions up to 4k (2160p). The ultra-flexible cable construction and the low profile, compact connector design make this cable an ideal fit for installations in tight spaces. The Ethernet capabilities of the cable allow a user to connect multiple Ethernet enabled HDMI devices through a single Ethernet connection for accessing interactive online content or updating device firmware.This fully-functional, high bandwidth cable is tested to perform at industry standards and is backed by a lifetime warranty. Experience the latest HDMI features including:
- 4K@50/60, (2160p), which is 4 times the clarity of 1080p/60 video resolution
- 3D video, Deep Color and x.v. Color
- Dolby True HD, DTS-HD Master Audio and up to 32 audio channels for a multi-dimensional immersive audio experience
- Up to 1536kHz audio sample frequency for the highest audio fidelity
- Simultaneous delivery of dual video streams to multiple users on the same screen
- Simultaneous delivery of multi-stream audio to multiple users (up to 4)
- Support for the wide angle theatrical 21:9 video aspect ratio
- Dynamic synchronization of video and audio streams
- CEC extensions for control of consumer electronics devices through a single control point
- HDMI Ethernet Channel technology and provides a bidirectional Ethernet communication at 100 Mbit/s
Note: Both the source device and display must support a HDMI feature in order to pass that feature through this cable
- Download a PDF with the technical specifications of this product on the Support tab or view the technical specifications of this product on the Specs tab
Features:
- Supports HDMI features including 4k resolution and 3D video
- Ultra-flexible cable construction
- Low profile, compact connector design
Specifications:
Product Specifications
- Color: Black
- Length: 6.00 Foot
- UPC: 757120413646
- Warranty: Lifetime
- Vendor: C2G
- Weight: 0.099 LB
Electrical Specifications
- HDMI features supported: 3D, 4k, High Speed
- Voltage rating: 30V
- Signal bandwidth: 3.4Gbps
- Nominal impedance: 100±10Ω
- Nominal capacitance: < 700pF
- Nominal velocity of propagation: 10.2Gbps
- DC resistance: 1450Ω/km max at 20°C
Physical Specifications
- Operating temperature: -25° - 85°C, 60-93% relative humidity
- Storage temperature: -25° - 85°C, 60-93% relative humidity
- Minimum bend radius: 6.5mm
- Conductor 1 (5 pair)
- Conductor type: 35AWG (7/0.05) tinned copper
- Insulation: HD-PE
- Drain wire: 34AWG (1/0.16) tinned copper
- Conductor 2 (4 conductors)
- Conductor type: 36AWG (7/0.05) tinned copper
- Insulation: HD-PE
- Overall Cable
- Foil shield: Aluminum foil, 100% coverage
- Braided shield: 16/5/0.06 tinned copper, 65% coverage
- Jacket: PVC, black
- Outer diameter: 3.6 ± 0.2mm
- Connectors (2)
- Connector type: 19 pin HDMI
- Plating: Gold
- Housing: PVC
