Key Features
- Connector 1: USB-C Male
- Connector 2: USB 3.0 B Male
- Black Color
Description
Connect a USB-B Device to a USB Type-C Port on a Laptop, Desktop Computer, Tablet, or Other Device
This USB 3.0 (USB 3.1 Gen 1) USB-C to USB-B cable is the perfect solution for connecting a hard drive, hub, or other device that has a USB B port to a computer, tablet or other device that has a USB Type-C port for USB 3.0 (USB 3.1 Gen 1) communication. The color coded USB Type-C connector allows this cable to be easily identified as a USB 3.0 (USB 3.1 Gen 1) cable and differentiated from other cables which may support a different feature set. The USB Type-C connector is smaller than traditional USB connector and features a symmetrical design which allows it to be easily connected on the first try. Additionally, the durability of the USB Type-C connector allows for up to 10,000 connection cycles. This cable supports a data rate up to 5Gbps for data transfer and sync with 5 volts and 1 amp of power for device operation and charging.
Note: This cable is designed to support USB 3.0 (USB 3.1 Gen 1) communication and features and is not able to support USB 3.1 Gen 2 Communication and features.
Features:
- Connect the USB-B port of a hard drive, hub or other device a USB Type-C port
- Designed to support USB 3.0 (USB 3.1 Gen 1) communication and features
- Backwards compatible with USB 3.0 devices
- Color coded blue and labeled to designate USB 3.0 (USB 3.1 Gen 1) feature support
Specifications:
- Color: Black
- Length: 3.00 Foot
- UPC: 757120288657
- Warranty: Lifetime
- Vendor: C2G
- Weight: 0.093 LB
- Electrical Characteristics
- Voltage Rating: 30V
- Dielectric Strength: AC-500V/1 Minute No Breakdown (EIA-364-20)
- Insulation Resistance: SR-PVC DC-500V 10MΩ/KM Min. at 20°C HDEP DC-500V 100MΩ/ KM Min. at 20°C (EIA-364-21)
- Conductor Resistance: 26AWG-148Ω/KM Max at 20°C / 28AWG-237Ω/KM Max at 20°C / 30AWG-376Ω/KM Max at 20°C / 32AWG-588Ω/KM Max at 20°C
- Physical Characteristics
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -25°C to 70°C
- Conductor 1 (x4)
- Material: Stranded Tinned Copper
- Size: 32AWG (7/0.80TC)
- Insulation: FM-PE+SKin
- Color: Pair 1 - Yellow/Blue (twisted pair) Pair 2 - Orange/Purple (twisted pair)
- Conductor 2 (x2)
- Material: Stranded Tinned Copper
- Size: 32AWG (7/0.80TC)
- Insulation: HD-PE
- Color: White/Green
- Conductor 3 (x2)
- Material: Stranded Tinned Copper
- Size: 26AWG (7/0.16TC)
- Insulation: HD-PE
- Color: Red/Black
- Drain Wire (x2)
- Material: Stranded Tinned Copper
- Size: 32AWG (7/0.80TC)
- Shield 1
- Material: Aluminum Wrap Coverage - 100%
- Shield 2
- Material: Braid 16/4/0.10TC
- Jacket
- Material: PVC
- Outer Diameter: 4.2mm
- USB 3.0 C Connector
- Gender: Male
- Insulation: Black
- Contact Material: Gold Flash
- Shell Material: Nickel Plated
- USB 3.0 B Connector
- Gender: Male
- Insulation: Black
- Contact Material: Gold Flash
- Shell Material: Nickel Plated
- Hood Type
- Molded
