Shure UA844+V/LC Antenna Distribution System (174-216 MHz)

Wideband VHF Four-Way Active Antenna Splitter and Power Distribution System without Cable (174-216 MHz)

It seems like there's never as much time as you'd like to do sound check. That's why UA844+SWB Antenna Distribution System lets you stretch the power of your antenna pairs, giving you more on-air channels in less setup time. So you can set it, forget it, and have more flexibility to make sure it all sounds perfect.

UA844+xx/LC is also available with cable: UA844+xx

UA844+xx/LC replaces UA844xx/LC. Antenna Splitter and Power Distribution System for receivers, 4-way active antenna splitter plus cascade port, different frequency versions available, external power supply.

Features:

• Five-way RF signal output
• Supports VHF QLX-D and ULX-D receivers
• Front-mounting antenna hardware
• Rack-mounting hardware
• 4 DC power feeds and for receivers (15V, 2.5A max)
• DC outputs for antenna bias (12V, 300mA max)

Includes:

• 1 UA844+ Antenna/Power Distribution System
• 1 PS45 power supply
• Two 6 ft. BNC cables
• 2 Bulkhead adapters
• 1 Rack mount Hardware kit
• 1 Literature Package
• 4 Non-locking DC power cables for QLXD4
• Two 22 in. BNC cable
