Yamaha MGX16 22-Channel Digital Mixing Console with Audio Interface (White)

16-input Digital Mixer with 15+1 Faders, 8 Mic Preamps, 4.3" Touchscreen, 16-track Recorder, Bluetooth, and DSP - White

The Yamaha MGX16 combines hands-on digital mixing, multitrack recording, and a 22-in/22-out USB audio interface in a compact console. Built for live sound, installed systems, podcasts, streaming, and music production, it provides eight microphone preamps and flexible routing for a range of audio setups. This model features a white finish.

Fifteen channel faders and a master fader put level control within reach, while a 4.3-inch touchscreen and five control knobs provide access to mixing functions. Built-in DSP offers sound processing and latency-free monitoring. Auto Gain and Clip Safe assist with level management, Simple and Standard modes let you choose your operating workflow, and Scene Recall lets you return to stored settings.

Connect the MGX16 to your computer for recording through its main 22-in/22-out USB interface at 32-bit/96 kHz. A separate 2-in/2-out USB interface adds another audio connection. For recording without a computer, capture up to 16 tracks directly to a microSD card at up to 24-bit/96 kHz. Bluetooth audio input and two-track microSD playback provide additional ways to bring audio into your mix.

With eight mono channels, four stereo channels, a Sound Pad channel, and two effects returns, the MGX16 accommodates microphones, instruments, and playback sources. A stereo bus and eight mix buses give you routing options for main outputs and additional mixes.

Included with the console are a PA-300C AC power adapter, Start Guide, Safety Guide, and software license cards for Cubase AI, WaveLab Cast, Steinberg Plus, and Basic FX Suite.

Features:

• 15 + 1 fader configuration (non-motorized fader)
• A 4.3-inch touchscreen with five control knobs
• Input mixing channels: 8 mono + 4 stereo + 1 Sound Pad + 2 FX return
• Busses: 1 STEREO + 8 MIX
• Local Inputs: 8 Combo (Mic/Line), 4 TRS (Line), 4 RCA (Line)
• Local Outputs: 2 XLR, 8 TRS Phone, 4 Headphones
• USB MAIN: 22 inputs / 22 outputs (32-bit / 96 kHz)
• USB SUB: 2 inputs / 2 outputs (16-bit / 48 kHz)
• microSD Card: 16-track recording / 2-track playback (24-bit / Up to 96 kHz)
• Bluetooth Audio Input: 2 inputs (Bluetooth 5.0, A2DP)
• Built-in DSP processor for professional sound and latency-free monitoring
• Assistive features: Auto Gain, Clip Safe, Simple / Standard mode, Scene Recall
• Included accessories: Start Guide, Safety Guide, Steinberg Software License Card x2 (Cubase AI + WaveLab Cast, Steinberg Plus), Basic FX Suite license card, AC Power Adapter (PA-300C)
