Key Features
- For Fixed Conference Installations
- 28 Sennheiser KE 10-237 Mic Capsules
- Automatic Beamforming Technology
- Focuses on Whoever Is Speaking in Room
- 2 x Dante Interface with RJ 45 Outputs
- 3-Pin Terminal for Analog Audio Output
- RJ 45 Ethernet for Network Control
- Sennheiser Control Cockpit Software
- Includes a 3-Pin Phoenix Connector
- 8 x Self-Adhesive Rubber Feet
Description
Ceiling Microphone with TruVoicelift - TeamConnect Ceiling 2 - Be Heard in the Room, Everywhere - White Finish
Sennheiser ceiling microphone with new and improved technology
The TeamConnect Ceiling 2, with its patented automatic dynamic beamforming technology, was already a leader in conference room audio technology. Now, with the addition of TruVoicelift and advanced zone control, TeamConnect Ceiling 2 combines the advantages of a boundary microphone and a microphone array. Therefore, it is the best solution for both (video) conferencing and in-room audio, for example in classrooms, lecture halls and boardrooms. TeamConnect Ceiling 2 now offers our customers unparalleled levels of control with the addition of a priority zone (allowing a single area in the room to be highlighted), 5 advanced exclusion zones (for pinpoint targeting and removal of unwanted noise sources) and more. All of these new features are activatable and configurable via the latest firmware update for the TeamConnect Ceiling 2 and via the latest version of Sennheiser Control Cockpit. Easy to install and, due to a flexible microphone ceiling mount system, easy to integrate. Let us help you understand the difference TeamConnect Ceiling 2 can make for you and your business.
*TeamConnect Ceiling 2 is sold under 2 variant article numbers. 509178 includes the SL CM EB mounting brackets (primarily US-market installations). 507488 is the standard variant with no mounting solutions included.
Background noise cancelling microphone
Highlights voice, reduces noise
With TruVoicelift, speech intelligibility in the meeting room can be significantly increased through targeted voice amplification. Additionally, a particular area of a room can be set as a priority zone to prioritize the speaking person over any others that are talking in the room. 5 advanced exclusion zones make it easier to define the position of noise sources to be ignored by the beam tracking. This concludes in automatic overall noise reduction.
Full control over the microphone array
Adjust the voice tracker from anywhere
Optimize your digital workflows with the Sennheiser Control Cockpit software. The ceiling microphone can easily be operated and monitored from anywhere in the corporate or campus network. This way, the adjustable microphone array can be controlled at any time.
Perfect Integration
For 100% connectivity - Connect the TeamConnect Ceiling 2 ceiling microphone via analogue or digital DANTE audio outputs to any conference system. The flexible connection options make the meeting and conference microphone even more agile and applicable for many different situations.
Easy to Install
Power-over-Ethernet (PoE) makes integration of the ceiling microphone very easy. An open media control protocol (API) allows you to make individual adjustments.
Features:
- 3 installation variants for the microphone ceiling mount:
- As individual as your meeting environment
- Ceiling-mounted
- The ceiling microphone TeamConnect Ceiling 2 can be installed on ceilings with an optional ceiling mount bracket.
- Flush-mounted
- The ceiling mic can be easily flush-mounted into standard false ceilings and captivates meeting rooms with its unobtrusive and aesthetically pleasing design.
- Suspended
- The suspended construction of the TeamConnect Ceiling 2 fits perfectly for particularly high ceilings. The microphone is simply hung from the ceiling thanks to the suspension kit (SL CM SK) accessories.
- Product variants
- The TeamConnect Ceiling 2 is available in the colors white RAL 9016 (Article No. 507488) or black RAL 9005 (Article No. 509161).
Specifications:
- Dimensions: 590 x 590 x 43 mm
- Microphone: 28 x Sennheiser KE10 pre-polarized condenser capsule
- Sound pressure level (SPL): max. 104 dB SPL
- Weight: 5670 g (12.5 lbs)
- Audio output: 1 x 3-pin terminals (Phoenix contact MCVW 1.5-3-ST-3.81); 2 x Digital Dante Network Audio (RJ45, can be configured to AES67 via Dante Controller)
- Dynamic range: 93 dB(A)
- Voltage: 44 - 57 V DC (via PoE IEEE 802.3af Class 3)
- Temperature Range:
Operation: 0 to 40°C (32 to 104°F)
Storage: -10 to 60°C (14 to 140°F) - Safety certification: UL62368 certification (Including UL2043 testing and compliance)
