Schoeps STC 22G ORTF Mounting Bar

Special Version of STC for (2) MK 22 Capsules with Active Cables or (2) CCM 22

The holder ensures that two cardioid microphones (CCM/MK 4) have the exact distance and angle to each other for the ORTF method.

An ORTF-like technique is achieved by using open cardioids (CCM / MK 22). However, due to the lower directivity of the open cardioids, the level difference becomes smaller and thus the recording angle becomes larger. The holder STC 22 is slightly longer to compensate for this with larger time differences. Thus, the same recording angle as in the ORTF technique is achieved.

Features:

• mounting adapter for CCM microphones, CMC 1 L or KC active cables
• for ORTF recording
• excellent stereophonic characteristics: very good localization, very good spatial quality

Specifications:

• STC 22
• Distance between the microphones: 210 mm
• Recording angle:
  with MK/CCM 4: 90 °
  with MK/CCM 22: 100 °
• Microphone Offset Angle: 110 °
• Stereophonic recording technique: quasi-ORTF
