Key Features
- 4 x Balanced XLR Inputs
- Selectable Phantom Power per Input
- Balanced Stereo XLR Outputs
- Selectable Mic/Line Level for XLR I/O
- 3.5mm Stereo Output
- 15 VDC Power Supply or Two 9V Batteries
Description
Four Channel XLR Stereo Mic or Line Mixer
The MX401 mixes 4 microphones or line level XLR's into two balanced Stereo outputs. The four XLR inputs, each have individually switchable phantom power, MIC or LINE level switch, Level control, and a Pan control. Two independant balanced, XLR outputs both with selectable MIC or LINE level. 1/8" inch Stereo Aux/Headphone output has been provided along with a Clip indicator, Power indicator, and Power switch. The unit is also powered by two 9-Volt alkaline batteries or the included 15VDC power supply. The MX401 replaces the previous MX124.
Features:
- Four balanced XLR Inputs
- Two balanced XLR Outputs
- Switchable Output Level ( Line level, or mic)
- Switchable Phantom Power for each input
- Level controls for each channel
- 3.5mm Stereo Output
- Rolls PS27s 15 VDC external power supply included
- Powered by two 9 volt batteries or the included power supply
Specifications:
- Input Impedance: 600 Ohms MIC - 10k Ohms LINE
- Output Impedance: 600 Ohms MIC - 10k Ohms LINE
- THD Noise:.02%
- S/N Ratio: 96 dB
- THD Noise: .02%
- Self Noise: -65 dB maximum, -90 dB typical
- Frequency Response:20 Hz - 20kHz ( 0 / -3 dB)
- Max Output Level: 14 dB
- Max Gain: 55 dB
- Current Draw: 30 mA with no Phantom Power or Signal
- Phantom Power: 15 VDC
- Power: 12-15VDC / < 300-500 mA
- Size: 8.5"w x 5.75"d x 1.5" h
- Weight: 2.05 lbs.
