Key Features
- Male 1/4" Mono Phone Plug
- Tip, Sleeve (TS) Connections
- Long Barrel
- Solder Cups
- Nickel Metal Housing
- Gold Contacts
- Full Box of 100 Connectors
Description
Male 1/4" TS Mono Long Barrel Plug, Cable End, Nickel Housing, Gold Contacts - Full Box of 100 Connectors
Mono 1/4" plug, long diecast silvery handle, gold plated contacts
Features & Benefits
- Mono 1/4" plug for multi-series engineering applications
- High quality materials, insuring best signal transmission
- Meet all prvailing standards
- Sturdt diecast metal shell, no rivets
- Gold plated sleeve and inner
Technical Information
- Product
- Title: NYS224G
- Connection Type: Mono 1/4" plug
- Electrical
- Dielectric strength: 0.5kV dc
- Insulation resistance: ＞1 GΩ
- Mechanical
- Lifetime: > 1000 mating cycles
- Cable O.D.: ≤9.5 mm
- Insertion force: ≤60 N
- Withdrawal force: ≤60 N
- Material
- Shell: Zinc alloy
- Shell plating: Nickel
- Bushing: POM
- Sleeve Plating: Gold
- Inner Plating: Gold
- Cable Clamp: Steel
- Environmental
- Flammability: UL 94 HB
- Solderability: IEC68-2-20
- Temperature range: -20°C to ﹢70°C
Details
- Manufacturer: Neutrik
- MPN: NYS224G
- Model Number: NYS224G
