Key Features
- 44U Racking Height
- Fully Welded Construction
- Built-In Horizontal Lacing Bars
- Racks Gang Together
- Front & Rear 10-32 Rackrail
- Includes Locking Rear Door
Description
44 Space (77") Video Rack with Horizontal Lacing Bars, 31" Deep, With Rear Door, Black Finish
The VRK-44-31H 31" Deep 44U Video Rack Enclosure with Rear Door from Middle Atlantic is a specialized video rack that provides 44U of rack space. It is constructed of steel and will support 2500 lbs of equipment in its standard configuration or up to 775 lbs under its seismic certification. This model comes standard with a vented rear key-locked door with UHF/VHF knockouts. The open top of the unit is configurable and (16) horizontal bars with 7" centers are also included for quick cable lacing.
This unit accepts standard 22" broadcast equipment and is UL Listed in the United States and Canada. Two pairs of threaded 10-32 rack rails are included. It is finished with a durable textured black powder coat. Optional horizontally split side panels are also available for this model.
Features:
- Fully welded construction for strength
- Built-in horizontal lacing bars on 7" centers for quick "tie-and-slide" lacing
- Racks gang together when fully loaded
- Standard front and rear adjustable 10-32 threaded rackrail with numbered spaces
- Includes partially vented locking rear door
-
Solid Construction
All-steel construction guarantees exceptional strength and years of use. -
No-Clog Rack-Rail Threads
All rack rails are finished in a durable "e-coat" to prevent clogged threads. -
Industry-Standard Design
Rack rails are labeled in EIA standard rack-space increments, allowing for easy equipment alignment. -
Customization
Pick and choose from Middle Atlantic's wide range of accessories to customize and expand your rack system. -
Pre-Installed Washers
Pre-installed washers on all 10-32 threaded rack screws save installation time. -
Grounding/Bonding Studs
Grounding/Bonding Studs have been provided to help you electrically ground and bond equipment per NEBS and NEC standards. -
Free Layout & Specifications Software
RackTools free layout and specification software is included for effective system design help.
Specifications:
- General Info
- Gangable: Yes
- finish: Textured Black Powder Coat
- UL Standards Tested: UL1678
- Listing Agencies/Third Party Information
- ASC E: 7-10
- RoHS: Yes
- Greenguard: Yes
- UL Listing No: E173107
- Seismic Rating: Yes
- Dimensions
- Usable Depth: 29
- Usable Height: 77
- Capacity Weight U S: 10000
- Depth U S: 31.4
- Height U S: 83.14
- Width U S: 22
- Primary Package Weight U S: 182
- Rack Units: 44
- Eco Information
- RoHS Compliant: Yes
- RoHS Conformant
- Technical Information
- Rackrail Type: 10-32
- Seismic Load Capacity: 740
- U L Load Capacity: 2500
- Material: Steel
- Mounting: Horizontal
