JBL VRX918SP 18" Powered Flying Subwoofer

18 in. High Power Powered Flying Subwoofer

The VRX918SP is a powered, suspendable subwoofer system containing a 2268FF neodymium magnet, patented Differential Drive, 18" woofer in a front-loaded, vented enclosure. The VRX918SP was designed specifically for use in arrays with the VRX932LAP Line Array speaker and VRX-AF Array Frame. In addition it may also be used in arrays consisting entirely of VRX918SP subwoofers.

Features:

• Built-in JBL Drivepack DPC-2 amplifier module designed by Crown provides 1500 Watts of peak Power. DSP based resident input module provides system optimization, EQ and crossover functionality.
• 18 inch, 2268FF dual voice coil, neodymium magnet Differential Drive woofer for high-power capacity and light weight.
• Integral rigging hardware for simple connection of enclosures and optional array frame.
• 20 mm threaded pole socket for solid, secure satellite speaker mounting.
• Large port area for reduced distortion.

Specifications:

• Power Rating: 1500 Watts Peak
• LF: Dual-Bridged Technology, Class D
• Frequency Range: 31 Hz - 220 Hz
• Dimensions (H x W x D): 508 mm x 597 mm x 749 mm (20.0 in x 23.5 in x 29.5 in)
• Frequency Response: 34 Hz - 220 Hz
• Maximum Peak Output: 126 dB SPL at 1m
• Bandpass Nominal Impedance: LF: 2 x 2 ohms
• LF Driver:
  1 x JBL 2268FF 457 mm (18 in) dual voice coil
  Differential Drive woofer with neodymium-magnet
• Audio Input Connector: XLR with loop through
• User Controls:
  Input Attenuator (0-16 dB)
  Selectable 80 Hz or 120 Hz Low Pass
  80 Hz High-Pass enable/disable for XLR loop thru.
• Signal Processing: DSP based, resident in Input Module
• System Management: DSP based limiters for mechanical and thermal protection
• AC Power Operating Range: 90-132 VAC or 216-264 VAC, 50/60Hz
• AC Line Voltage: User selectable: 120V/240V (-15%, +10%)
• AC Input Connector: Neutrik PowerCon (NAC 3MPA)
• AC Loop Through Connector: Neutrik PowerCon (NAC 3MPB)
• AC Current Requirements: 6A per system at 120V, 3A per system at 240V
• Enclosure: 18 mm birch plywood.
• Suspension / Mounting: Optional VRX-AF line-array frame kit or 10 mm forged eyebolts
• Finish: Black DuraFlex finish
• Grille: Powder coated, black, 16-gauge perforated steel with
• acoustically transparent foam
• Net Weight: 38.5 kg (85 lb)
• Optional Accessories:
  VRX-AF array frame
  SRX718S-CVR: Pull-over padded cover (works with WK-4S)
  SS4-BK adjustable satellite speaker pole WK-4S Caster kit
