Key Features
- Standard HDMI Cable with Ethernet
- Supports up to 1080i Resolution
- Gold Plated Connectors
- In-Wall Rated CL2
Description
High retention HDMI Cables that provide 3 times greater port retention than standard HDMI connectors.
This Standard Speed HDMI Cable With Gripping Connectors is the perfect solution for connecting multimedia source devices in home theater, desktop or commercial audio video applications requiring up to 1080i resolution. Ensure that your most critical equipment maintains signal with the gripping connectors which provide 3 times the port retention of a standard HDMI connector. The Ethernet capabilities of the cable allow a user to connect multiple Ethernet enabled HDMI devices through a single Ethernet connection. This fully-functional, digital video and audio cable is tested to perform at industry standards and is backed by a lifetime warranty.
Note: Both the source device and display must support a HDMI feature in order to pass that feature through this cable
Features:
- Three times greater port retention than standard HDMI connectors
- Standard Speed HDMI cable including Ethernet
- Supports up to 1080i video resolution
- Gold plated connectors
- In-wall rated CL2
Specifications:
-
Product Specifications
- Color: Black
- Length: 50.00 Foot
- Jacket Rating: In Wall
- UPC: 757120296867
- Warranty: Lifetime
- Vendor: C2G
- Weight: 3.870 LB
-
Electrical Specifications
- Voltage: 30V
- Dielectric Strength: AC-500V/S Minute
- Insulation Resistance: DC 500 100MΩ Km Min. at 20°C
- Conductor Resistance: 24AWG 93Ω/Km Mat at 20°C
-
Physical Specifications
- Cable Outer Diameter: 10.50mm
- Shield: Aluminum Mylar - 100% Coverage 25% Overlap minimum / Braid - A-M Alloy (24/11/0.12mm)
- Drain: 24AWG Tinned Copper (7/0.20mm)
- Conductor
- Material: Tinned Copper
- Size: 24AWG (7/0.20mm)
- Insulation Pairs: FM-PE+Skin
- Insulation Single: HD-PE
- HDMI Connector
- Gender: Male x2
- Port Retention: 6.6lbs Minimum Withdraw Force
- Insulation: Black
- Contact Material: Gold Flashing
