AKG PCC170 Professional Boundary Layer Microphone

Surface-Mount Supercardioid Boundary Layer Mic

Taking Care Of Business

The PCC170 and the PCC170 SW are professional boundary layer microphones with supercardioid polar pattern to minimize background noise and feedback. The microphones are designed for use on boardroom tables or lecterns. Both microphones provide a bass-tilt switch, allowing the user to tailor the low-end response and reduce subsonic noise. The included RFI suppression ensures trouble-free operation even with active cell phones nearby. The PCC170 SW has a silent-operating programmable membrane switch that can be configured for touch on/off, momentary on or momentary off. For easy installation, both microphones offer an XLR connector and a detachable cable.

The PCC-170 is a surface-mounted supercardioid microphone of professional quality. This handsomely styled unit is appropriate for use on the most elegant boardroom table or lectern. Other applications include churches, courtrooms and council chambers. Because of its highly directional pickup pattern, the PCC-170 minimizes background noise and feedback. The microphone reproduces the voice with a clean, clear and natural sound.

Since the microphone capsule is placed on a boundary or surface, direct and reflected sounds arrive at the diaphragm in-phase. This coherent addition of direct and reflected waves increases sensitivity 6 dB and prevents phase cancellations. The mic capsule is small enough to ensure phase coherency up to the highest frequencies in the audible spectrum, resulting in a wide, smooth frequency response free of phase interference. Clarity and reach are also enhanced.

Self-contained electronics eliminate the need for an in-line preamp. Powered by 12-48 V phantom power, the PCC-170 has a low-impedance mic- level balanced output which permits long cable runs without hum pickup or high-frequency loss.

RFI suppression is included. Self-noise is low and sensitivity is very high and an RFI suppression is included. A bass-tilt switch allows the user to tailor the low-end response for particular applications.

Features:

• Supercardioid Polar Pattern - Offers High Gain Before Feedback
• Pcc (Phase Coherent Cardioid) Technology - For Optimum Speech Intelligibility
• Three-Position Bass-Tilt Switch - For Optimized Suppression Of Subsonic Noise
• Silent-Operating On/Off Switch (Pcc170Sw Only) - To Reduce The Number Of Simultaneously Open Mics
• Detachable Cable - Easy To Install And Service

Specifications:

• Supercardioid polar pattern offers high-gain-before-feedback
• Phase coherent cardioid design prevents coloration from surface sound reflections
• Wide and smooth frequency response
• Three-position bass-tilt switch
• Small and inconspicuous
